Reduce costs across the board
Get your print costs back under control and reduce waste with Canon’s uniFLOW print management software that lets you determine who gets access to colour, quantity and single or double-sided printing.
Maximise efficiency with cloud connection
Maximise efficiency with a range of software and MEAP-based solutions that let you print from mobile devices, internet-connected devices and cloud-based services, as you need.
Achieve more every day
Create new efficiencies and achieve business goals with this quiet office printer that’s controlled from a tilt screen and loaded with hardware and software solutions for minimal management.
Be responsive to changing needs
On the go? Your ADVANCE DX C5870i is ready with a set of simple mobile solutions that will enable you to scan, copy and print from wherever you are, whenever you need.
Vivid, vibrant and accurate
New toner CS2 (Constantly Stable 2) provides a wider colour gamut that will help you achieve images that are vivid, vibrant and in high resolution.
| Type | Color Laser Multifunctional |
| Core Functions | Standard: Print, Copy, Scan, Send, Store Optional: Fax |
| Control Panel | 10.1″ TFT LCD WSVGA Color Flat-panel |
| Memory | 5.0 GB RAM |
| Solid State Drive | Standard: (SSD) 256 GB Optional: (SSD) 256 GB, 1 TB |
| Interface Connection | Network: 1000Base-T/100Base-TX/10Base-T, Wireless LAN (IEEE 802.11 b/g/n) Optional: NFC, Bluetooth Low Energy Others Standard: USB 2.0 (Host) x1, USB 3.0 (Host) x1, USB 2.0 (Device) x1 Optional: Copy Control Interface |
| Paper Capacity (Letter, 20 Lb. Bond) | Standard: 1,200 Sheets Maximum: 6,350 Sheets |
| Paper Sources (Letter, 20 Lb. Bond) | Standard: Dual 550-sheet Paper Cassettes, 100-sheet Stack Bypass Optional: Dual 550-Sheet Paper Cassettes (Cassette Feeding Unit-AM1), 2,450-Sheet High Capacity Paper Cassette (High Capacity Cassette Feeding Unit-C1), 2,700-Sheet Paper Deck (Paper Deck Un |
| Paper Output Capacity (Letter, 20 Lb. Bond) | Standard: 250 Sheets Maximum: 3,450 Sheets (with Staple Finisher-AB1 or Booklet Finisher-AB1 and 3rd Copy Tray Kit-A1) |
| Finishing Capabilities | Standard: Collate, Group With Options: Collate, Group, Offset, Staple, Saddle-Stitch, Hole Punch, Eco Staple, Staple On Demand |
| Supported Media Types | Multi-Purpose Tray: Thin, Plain, Recycled, Color, Heavy, Coated, Tracing, Bond, Transparency, Label, Pre-punched, Letterhead, Tab, Envelope Paper Cassettes: Thin, Plain, Recycled, Color, Heavy, Bond, Transparency, Pre-punched, Letterhead, Envelope |
| Supported Media Sizes | Upper Cassette: Letter, Executive, Statement-R, Envelope [No.10 (COM10), Monarch, DL, ISO-C5], Custom Size (3-7/8″ x 5-7/8″ to 11-3/4″ x 8-1/2″) Lower Cassette: 12″ x 18″, 11″ x 17″, Legal, Letter, Letter-R, Executive, Statement-R, Envelope [No.10 (COM10) |
| Supported Media Weights | Cassettes: 14 lb. Bond to 140 lb. Index (52 to 256 g/m2 ) Stack Bypass: 14 lb. Bond to 110 lb. Cover (52 to 300 g/m2 ) Duplexing: 14 lb. Bond to 140 lb. Index (52 to 256 g/m2 ) |
| Print/Copy Speed (Bw And Color) | Up to 70 ppm (Letter);Up to 42 ppm (Letter-R); Up to 40 ppm (Legal); Up to 35 ppm (11″ x 17″) |
| Warm-Up Time | From Power On: Approx. 6 Seconds From Sleep Mode: Approx. 7 Seconds Quick Startup Mode: Approx. 4 Seconds |
| Print Resolution (Dpi) | 1200 x 1200 |
| Standard Page Description Languages | UFR II, PCL6, Adobe PS 3 |
| Supported Files | PDF, TIFF, JPEG, EPS, XPS |
| Printing From Mobile And Cloud-Based Services | A range of standard and optional software and MEAP-based solutions (including AirPrint, Mopria, Universal Print by Microsoft, Canon PRINT Business, and uniFLOW Online) are available to provide printing from mobile devices or internet-connected devices and |
| Fonts | PCL: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T (Japanese, Korean, Simplified and Traditional Chinese), Barcode Fonts PS: 136 Roman |
| Operating System | UFRII/PS: Windows 7/8.1/10/Server2008/ Server2008 R2/Server2012/Server2012 R2/Server2016/Server2019, Mac OS X (10.11 or later) PCL: Windows 7/8.1/10/Server2008/ Server2008 R2/Server2012/Server2012 R2/Server2016/Server2019 PPD: Windows 7/8.1/10, Mac OS X(1 |
| First-Copy-Out-Time | As fast as 2.7 seconds (BW)/ 3.7 seconds (Color) |
| Copy Resolution (Dpi) | 600 x 600 |
| Multiple Copies | Up to 999 |
| Magnification | 25%-400% (1% Increments) |
| Preset Reduction / Enlargement | 25%, 50%, 64%, 73%, 78%, 100% (1:1), 121%, 129%, 200%, 400% |
| Type | Single-Pass Duplexing Automatic Document Feeder |
| Document Feeder Paper Capacity | Up to 200 Sheets (20 lb. Bond) |
| Document Feeder Supported Media Sizes | 11″ x 17″, Legal, Letter, Letter-R, Statement, Statement-R, Custom Size: 2-3/4″ x 5-1/2″ to 12″ x 17″ |
| Document Feeder Supported Media Weights | Single-Sided Scanning: 13.3 lb. Bond to 80 lb. Cover (50 to 220 gsm) (BW, CL) Double-Sided Scanning: 13.3 lb. Bond to 80 lb. Cover (50 to 220 gsm) (BW, CL) |
| Platen Acceptable Originals | Sheet, Book, 3-Dimensional Objects |
| Pull Scan | Color Network ScanGear for both Twain and WIA Supported OS: Windows 7/8.1/10/Server 2008/ Server 2008 R2/Server 2012/ Server 2012 R2/Server 2016 |
| Scan Resolution (Dpi) | Scan for Copy: 600 x 600 Scan for Send: (Push) 600 x 600 (SMB/FTP/WebDAV/ IFAX), (Pull) 600 x 600 Scan for Fax: 600 x 600 |
| Scan To Mobile Devices And Cloud-Based Services | A range of solutions is available to provide scanning to compatible mobile devices and certain cloud-based services depending on your requirements. |
| Scan Speed (Letter) | Single-sided Scanning: 135/135 (300 dpi), 80/80 (600 dpi) Double-sided Scanning: 270/270 (300 dpi), 160/90 (600 dpi) |
| Destination | Standard: E-mail/Internet FAX (SMTP), SMB3.0, FTP, WebDAV, Mail Box Optional: Super G3 FAX, IP Fax |
| Address Book | LDAP (2,000)/Local (1,600)/Speed Dial (200) |
| Send Resolution | Push: Up to 600 x 600 Pull: Up to 600 x 600 |
| Commuication Protocol | File: FTP(TCP/IP), SMB3.0 (TCP/IP), WebDAV Email: SMTP, POP3 |
| File Format | Standard: TIFF, JPEG, PDF (Encrypted, Compact, Searchable, Apply Policy, Optimize for Web, User Signature, PDF A/1-b, Limited Color, Device Signature, User Signature), XPS (Compact, Searchable, Device Signature, User Signature), Office Open XML (PowerPoin |
| Modem Speed | Super G3: 33.6 Kbps G3: 14.4 Kbps |
| Compression Method | MH, MR, MMR, JBIG |
| Resolution | 400 x 400, 200 x 400, 200 x 200, 200 x 100 |
| Sending / Recording Size | Statement-R to 11″ x 17″ |
| Fax Memory | Up to 30,000 Pages (2,000 jobs) |
| Speed Dials | Max. 200 |
| Group Dials / Destinations | Max. 199 Dials |
| Sequential Broadcast | Max. 256 Addresses |
| Memory Backup | Yes |
| Mail Box Simple (Number Supported) | 100 User In-boxes, 1 Memory RX In-box, 50 Confidential Fax In-boxes, Maximum 10,000 Pages (2,000 jobs) Stored |
| Advanced Box | Communication Protocol: SMB or WebDAV Supported Client PC: Windows (Windows 8.1/10) Concurrent Connections (Max.) SMB: 64 WebDAV: 3 |
| Advanced Box Available Disc Space | Approx. 16 GB (Standard HDD) Approx. 480 GB (With Optional 1 TB HDD) |
| Authentication And Access Control | User Authentication (Picture Login, Picture and PIN Login, Card Login, Username and Password Login, Function Level Login, Mobile Login), Department ID Authentication (Department ID and PIN Login, Function Level Login), uniFLOW Online Express (PIN Login, P |
| Document Security | Print Security (Secure Print, Encrypted Secure Print, Forced Hold Printing, uniFLOW Secure Print), Receive Data Security (Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Sig |
| Network Security | TLS 1.3, IPSec, IEEE802.1X authentication, SNMP V3.0, Firewall Functionality (IP/MAC Address Filtering), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/ Wired LAN), Disabling Unused Functions (Enabling/ Disabling Protocols/Applications, Enabling/ |
| Device Security | Protecting SSD Data [SSD Data Encryption (FIPS140-2 Validated), SSD Lock], Standard SSD Initialize, Trusted Platform Module (TPM), Job Log Conceal Function, Protecting MFD Software Integrity, Checking MFD Software Integrity (Verify System at Startup, Runt |
| Device Management And Auditing | Administrator Password, Digital Certificate and Key Management, Audit Log, Cooperating with External Security Audit System (Security Information and Event Management), Image Data Logging, Security Policy Setting |
| Operating Environment | Temperature: 50 to 86º F Humidity: 20 to 80% RH (Relative Humidity) |
| Power Requirements | 110-127V, 60Hz, 12A |
| Power Consumption | Maximum: Approx. 1,800 W Standby: Approx. 56.1 W Sleep Mode: Approx. 0.8 W Typical Electricity Consumption (TEC) Rating: 0.86 kWh |
| Standards | ENERGY STAR Certified Rated EPEAT Gold |
| Toner | GPR-61 Toner BK/C/M/Y GPR-61L Toner C/M/Y |
| Toner Yield (Estimated @ 5% Coverage) | GPR-61 Toner BK: 71,000 Pages GPR-61 Toner C/M/Y: 60,000 Pages GPR-61L Toner C/M/Y: 26,000 Pages |
| Dimensions (W X D X H) | 24-3/8″ x 28-1/2″ x 36-7/8″ |
| Installation Space (W X D X H) | Basic: 44-7/8″ x 45-3/4″(Right Cover Open with Multi-purpose tray extended + Cassette Drawers Open) Fully Configured: 73-1/2″ x 45-3/4″ (Staple Finisher-AB1 or Booklet Finisher-AB1 with the extension tray extended + Paper Deck Unit-F1 + Cassette Drawers o |
| Weight | Approx. 238.1 lb. |
Not sure which machine is right for you? Our sales team has an in-depth understanding of the capabilities of our machines and can guide you in selecting the copier or printer that suits your business needs. Book an obligation-free consultation with us and let us walk you through the options.
